23" (580mm) x 5mm notched disc blade with a flat center for Pöttinger Terradisc compact disc harrows. The 4-bolt, 4.33" bolt circle matches the Terradisc hub for a direct swap.
Key Features
- Notched edge for cutting residue and pulling into hard ground
- Flat center seats flat on the hub
- 4 holes on a 4.33" (110mm) circle for M12 bolts
- Direct replacement for Pöttinger 9771.03.025.0
Fits
- Pöttinger Terradisc 3001, 3501, 4001, 4001K, 5001K, 6001K
- Pöttinger Terradisc 4001T, 5001T, 6001T, 8001T, 10001T
Replaces OEM #
Pöttinger 9771.03.025.0, 9771.03.025.1, 9771.03.028.1; also 771030251-23-19
Specs
- Diameter: 23" (580mm)
- Thickness: 5mm
- Edge: notched, flat back
- Bolt pattern: 4 holes on 4.33" (110mm) circle, M12 bolts
Hardware
Mount with RLH42065 M12-1.75 x 40mm Class 8 bolts and RLH60204 12mm Stover lock nuts.
OEM names and numbers are for reference only.
| Machine | Make | Model |
|---|---|---|
| Disc | Pottinger |
