Gauge Wheel Double Row 40mm Bearing, 2-13/16" X 1-3/16", AN212132, 324461A1

Availability:
In stock
(No reviews yet) Write a Review
$8.77
Adding to cart… The item has been added
SKU:
RLP1452
Categories:
Featured Products,Grain Drill Parts,Hardware,Planter Parts,Tillage Parts,Grain Drill Parts/John Deere,Grain Drill Parts/Case-IH,Grain Drill Parts/Great Plains,Grain Drill Parts/Landoll,Grain Drill Parts/Crustbuster,Grain Drill Parts/Sunflower,Grain Drill Parts/Krause,Grain Drill Parts/Hiniker Air Seeder,Hardware/Bearings,Planter Parts/Kinze,Planter Parts/Case IH,Planter Parts/White,Planter Parts/John Deere,Tillage Parts/Row Crop Cultivator,Grain Drill Parts/John Deere/Air Seeder,Grain Drill Parts/Case-IH/500/500T,Grain Drill Parts/Case-IH/SDX30/SDX40 Air Seeder,Grain Drill Parts/Great Plains/Bearings,Hardware/Bearings/Prelube,Planter Parts/Kinze/Gauge Wheel,Planter Parts/Kinze/Bearings,Planter Parts/Case IH/Gauge Wheel Parts & Assemblies,Planter Parts/Case IH/Bearings,Planter Parts/John Deere/7000 and 7100 Series,Planter Parts/John Deere/7200 7300 1700 and DB Series,Tillage Parts/Row Crop Cultivator/Cultivator Repair Parts,Grain Drill Parts/John Deere/Air Seeder/Gauge Wheels,Grain Drill Parts/John Deere/Air Seeder/Bearings,Grain Drill Parts/Case-IH/SDX30/SDX40 Air Seeder/Gauge Wheels,Planter Parts/John Deere/7000 and 7100 Series/Gauge Wheels,Planter Parts/John Deere/7000 and 7100 Series/Bearings,Planter Parts/John Deere/7200 7300 1700 and DB Series/Gauge Wheels,Planter Parts/John Deere/7200 7300 1700 and DB Series/Bearings,Tillage Parts/Row Crop Cultivator/Cultivator Repair Parts/Bearings,Planter Parts/Monosem,Planter Parts/Martin Till Replacement Parts,Planter Parts/Great Plains,Planter Parts/John Deere/7000 and 7100 Series/Gauge Wheels/Repair Parts,Planter Parts/Great Plains/Bearings,Planter Parts/John Deere/7200 7300 1700 and DB Series/Gauge Wheels/Gauge Wheel Parts,Planter Parts/Monosem/Gauge Wheel Parts & Assemblies,Planter Parts/Kinze/Gauge Wheel/Misc. Parts,Grain Drill Parts/Case-IH/500/500T/Gauge wheels,Planter Parts/White/6000, 8000 Series,Planter Parts/White/9000 Series,Planter Parts/White/6000, 8000 Series/Bearings,Planter Parts/White/9000 Series/Bearings
Replacement Numbers:
854-003, AN212132, 324461A1, AG301P, 306007A1, 822-170C, GA6171, 900125, 7140A, 854003, 2570-069, 5203VVAN, DAC164044-2RS
Availability:
In stock.

40 mm double row gauge wheel bearing that replaces John Deere AN212132 and Case IH 324461A1. One of the most common planter and drill bearings: gauge wheels, closing wheels, press wheels and markers across John Deere, Case IH, Kinze, Great Plains, New Holland, White and more.

Key Features

  • Double row ball bearing, 40 mm OD
  • Replaces John Deere AN212132, Case IH 324461A1, Kinze GA6171, Great Plains 822-170C, AGCO 854-003
  • Fits gauge wheels, rubber and cast closing wheels, press wheels and 4 bolt notched marker hubs
  • Need more seal protection in dusty or wet conditions? See RLP1452HD, the 6-lip-seal version

Fits

  • Case IH: gauge wheel on 1200 series s/n CBJ0001611 & up; SDX30, SDX40 air seeders; 500, 500T Precision Disk Drills
  • John Deere planters: all gauge wheels on XP, XP Pro; 1530, 1535 with XP. Rubber closing wheel on MaxEmerge® Plus, Pro, XP, XP Pro; 1530, 1535
  • John Deere drills: fits all 750, 1520, 1530, 1535, 1560, 1565, 1590, 1690, 1850, 1860, 1890. Cast closing wheel arm on 1560, 1565, 1590, 1690, 1835, 1860, 1890, 1895, 1990
  • John Deere markers: 4 bolt notched marker blades on 1700 and DB series planters; 7200, 7240, 7300, 7340 built 1995 and after; 4 bolt notched marker on 1500 series
  • John Deere 2510H applicator: gauge wheel and cast sealing wheel
  • Kinze: gauge wheel, closing wheel bearing
  • Great Plains: 2" x 13", 3" x 13" press wheels 1997 and after with steel wheel halves; 2.5" x 16", 3" x 16", 4.5" x 16" gauge wheels on planters and 10H, 15, 25 series drills 1998 & after with 15" openers
  • Hiniker: gauge wheel on late 4200 air seeders
  • Martin: spading closing wheels on late 1700 with MaxEmerge® Plus, XP; John Deere 7000-7100; Kinze®; White 6000, 8000. Fits Martin closing wheel hub
  • Monosem Plus: gauge wheel on late models and closing wheels
  • New Holland: SP280, SP380, SP480, SP580 all s/n PNL001065 & up; P2080, P2085 Disk Drills
  • White: gauge wheel on 8000, 9000 series. Late 6000; 8000, 9000 rubber or cast dual closing wheels
  • CrustBuster, Krause, Landoll, Sunflower, Sukup: grain drill gauge wheels

Replaces OEM #

John Deere AN212132; Case IH 324461A1, 306007A1; Kinze GA6171; Great Plains 822-170C; AGCO 854-003; also 854003, AG301P, 900125, 7140A, 2570-069, 5203VVAN, DAC164044-2RS

Specs

  • Type: double row ball bearing
  • Outside diameter (OD): 40 mm
  • Bore (ID): approx. 16 mm (5/8 in.), per John Deere AN212132 specs
  • Size as listed: 2-13/16" x 1-3/16"
  • Application: gauge wheel assembly, closing wheel, press wheel, marker hub

Heavy-duty option

RLP1452HD is the same 40 mm double row bearing with 6 lip seals for extra protection against dirt and water.

Inspection tip

Spin the gauge or closing wheel by hand. Roughness, wobble or grinding means the bearing is going; replace it before it locks up and wears the wheel or arm.

OEM names and numbers are for reference only.

Machine Make Model
Air Seeder/Drill,Cultivator,Planter,Tractor Case,John Deere,Sunflower,White 1560,1565,1590,1690,1850,1860,1890,1500,1895,1990
